StreamLiner™
Pairing max wall thicknesses of 0.001″ (0.025 mm) and below with best-in-class tensile strength, free-extruded StreamLiner™ catheter liners enable advanced catheter designs with smaller profiles or larger working channels.
Features & Benefits:
- Free-extruded
- Strongest liners in the StreamLiner™ family
- Nominal wall thicknesses: 0.0005″ – 0.00075″ (0.0127 mm – 0.01905 mm)
StreamLiner™ OTW
Extruded over-the-wire, StreamLiner™ OTW helps bridge the gap between film-cast and free-extruded liner technology. Blending strength and flexibility with wall nominal thicknesses as low as 0.0004″ (0.0102 mm), StreamLiner™ OTW catheter liners open new pathways for delivering lifesaving therapies.
Features & Benefits:
- Extruded over SPC wire
- Blend of strength and flexibility
- Nominal wall thicknesses: 0.0004″ – 0.00075″ (0.0102 mm – 0.01905 mm)
StreamLiner™ NG
StreamLiner™ NG is the latest addition to the StreamLiner™ family. Thanks to Zeus’ proprietary film-cast process, which helps reduce surface imperfections and pinholes, StreamLiner™ NG catheter liners take flexibility, mechanical performance, and reliability to the next level while still featuring the exceptional sizing and tolerances of previous StreamLiner™ generations.
Features & Benefits:
- Proprietary film-cast process
- Most flexible StreamLiner™ yet
- Max wall thicknesses up to 0.001″ (0.025 mm)
Free extruded StreamLiners™ are available with inside diameters (IDs) ranging from 0.004″ – 0.120″ (0.102 mm – 3.048 mm). StreamLiner™ OTW is available in IDs from 0.013″ – 0.0915″ (0.330 mm – 2.3241 mm). StreamLiner™ NG is available in IDs from 0.017″ – 0.0915″ (0.432 mm – 2.3241 mm).
Product Sheet
StreamLiner™ Series
Capabilities, sizing, properties, & more.
Download Now
Request a Prototype
